glTF Skin Roundtrip

A runnable example that rigs a mech scorpion — 21 bones: a body, a five-segment tail and stinger, two three-bone claws (arm, hand, movable finger), eight legs; two-bone blends in the rubber boots at every flexing joint — exports it with bpy.ops.export_scene.gltf (export_skins=True), parses the file, re-imports it, and verifies the whole skinning contract against the authored rig, following depsgraph-and-evaluated-data.

Pipeline arc: modeling/LOD in lod-decimate-chain, weighting in vertex-weight-limit, export in gltf-export-roundtrip — this is the skinning counterpart to the crate's geometry round-trip. Tangent frames for the normal maps are in triangulate-tangents.

What it witnesses: the skinned-mesh export contract the geometry round-trip left uncovered.

• The skeleton survives. skins[0].joints names every bone; the re-imported armature carries the same 21 bones, the same parent chain, and rest matrices within 2.3e-06 — the +Y-up conversion applies to bone nodes exactly as it does to meshes, whichever way a bone points (tail +Y, claws -Y, legs +/-X).
• The weights survive. Every primitive carries JOINTS_0/WEIGHTS_0; per-vertex weights on disk sum to 1 (err 3.0e-08; 840 disk vertices carry two influences); the re-imported vertex groups match the authored groups bit-exactly (w_err 0.0), compared as straddle-safe position keys, the same protocol as the crate example. Every split copy at a position is compared, not just one: the exporter splits vertices per normal, and each copy carries its own JOINTS_0/WEIGHTS_0, so one corrupted copy must not hide behind a good twin.
• The deformation survives. Posed identically, the re-imported rig's evaluated mesh matches the original's within 6.0e-07 — linear blend skinning through the file format. The comparison is by rest-position key, never sorted multisets: the exporter welds duplicate loops (9960 here), so cardinalities differ and a naive sorted zip mispairs vertices (a phantom 2.29 "deviation" measured and fixed during authoring).
• The mesh must be parented to the armature. The exporter warns "Armature must be the parent of skinned mesh" and picks an armature by name otherwise — with two rigs in the file it can bind the wrong one.

What each check catches on failure: exporting with export_skins=False (exit 5 — no skin on disk), stripping the weights (exit 4 — no vertex groups), nudging one re-imported weight (exit 18 — 0.99), moving one re-imported bone's rest tail 1 mm (exit 14 — 3.9e-03), and posing the re-imported rig differently (exit 19 — deformation deviates 0.13).

Straddle-safe keys, for real. A float32 round-trip can land a coordinate on the far side of a 1e-4 rounding boundary, so lookups also try the 26 neighbouring keys. Those neighbours must themselves be rounded: 0.3601 + 1e-4 in binary floating point is not the key 0.3602. The first version of this example added the offset without rounding, so only the exact key ever matched. It passed by luck until the redesign lowered the body to z = 0.36, and then it reported a phantom weight loss (exit 18, 1.0).

Version witness: the skins pipeline is stable across Blender 4.5 LTS, 5.1 and 5.2 LTS — every measured value matches to the digit on 4.5.11, 5.1.2 and 5.2.1.

The render is a standoff. On the left, the authored scorpion holds the guard pose the check compares: tail coiled tight over its back, claws tucked, pincers shut. On the right is the actual re-imported mesh, driven through its imported armature into a different pose: the tail rears high to strike, the claws are raised and the pincers gape. A file that lost the skin, the joints, or the weights could not follow that pose. The rubber boots at the joints bend smoothly and the plates stay rigid, which is the linear blend skinning surviving the format. The two poses differ on purpose, so the eye has something to compare. Two identical copies would render the same whether or not the round-trip worked.

Both rigs are posed by rest-space axes in quaternions, and the yaw is composed into each armature's world matrix, because the glTF importer leaves its armature in quaternion mode, where rotation_euler does nothing. Framing is measured by gallery_framing (fill 0.856 x, minimum margin 0.072). The asset floors are measured by gallery_asset_quality (5 materials: hazard paint, gunmetal, chrome, rubber, venom glow; edge90 0.001).

Run#

# Cheap correctness check (no render) — the CI check:
blender --background --python gltf_skin_roundtrip.py --

# Falsifier: export_skins=False. Must exit non-zero.
blender --background --python gltf_skin_roundtrip.py -- --no-skins

# Also render a still (EEVEE on a GPU host; use --engine cycles on GPU-less hosts):
blender --background --python gltf_skin_roundtrip.py -- --output scorp.png
blender --background --python gltf_skin_roundtrip.py -- --output scorp.png --engine cycles

Exit codes#

Per-script sequential checks. 9 is a valid check code; there is no rule against it.

On the --output path only, which runs after every check has passed, 10 also means a gallery_framing violation and 11 a gallery_asset_quality floor violation. The shared helpers own those codes, and the log line says which one fired.

The blender-smoke workflow runs the check on Blender 5.2 LTS and 4.5 LTS (5.1 on the weekly cron, the needs-5.1 PR label, or manual dispatch). Smoke does not pass --output. Its catalog falsifier is --no-skins (expects exit 5).
