Shipping Crate
A procedural shipping crate through UVs, bake, LOD, collider, and Unity glTF, asserting recomputed budgets rather than an API contract.
Rendered headless by the showcase piece itself. Select it to enlarge.
witnesses Recomputed: 9380 tris, three materials with face floors, UVs in 0..1 with zero AABB overlap, outer AABB 1.312×1.312×1.761 m, LOD ratios in band, convex collider 258 tris, hygiene zero (loose, non-manifold, doubles, n-gons), zero coplanar cross-shell face pairs, all 12 bottom-course stones on the floor, each post tenoned 18 mm into the measured coping and standing under a roof hip corner, the bucket hanging 0.10 m clear of the coping, grounded zmin, non-empty glTF. --stand-posts exits 15 on the z-fight budget; --float-stone exits 16 on the named-support budget; --shallow-tenon and --drop-bucket exit 18; --turn-posts exits 19 on post placement; --skip-decimate exits 9 on the LOD1 ratio budget; --lift-z exits 16 on the grounded budget.
category Village
blender --background --python showcase/stone-well/stone_well.py --
A showcase piece, not an example. Procedural round stone well (running-bond bricks, curb, four posts, shingled pyramid roof, windlass, rope, bucket) then the shipped pipeline: unique-cell UVs, Cycles high-to-low normal bake, LOD chain, convex collider, Unity glTF export.
It asserts budget conformance of the generated result. It does not witness an API contract. "It rendered without error" is not a check.
Composes skills mesh-editing-and-bmesh, bake-high-to-low, depsgraph-and-evaluated-data, engine-export-presets, and snippets bake_normal_high_to_low.py, setup_bake_target_image.py, lod_chain.py / decimate_to_budget.py, convex_hull_collider.py, export_preset_unity.py (helpers copied, not imported as a package).
Budgets#
Declared as named constants; every gate recomputes from the mesh, materials, UVs, evaluated LOD, collider, or export file.
| Axis | Declared | Measured (4.5.11 / 5.1.2 / 5.2.1) |
|---|---|---|
| Base triangles | 8280–9500 | 9380 / 9380 / 9380 |
| LOD1 ratio | 0.32–0.62 of base | 0.5000 / 0.5000 / 0.5000 |
| LOD2 ratio | 0.10–0.35 of base | 0.2198 / 0.2198 / 0.2198 |
| Materials | exactly 3 distinct | 3 |
| Material faces | stone ≥ 3000, wood ≥ 600, metal ≥ 100 | all above |
| UVs | in 0..1, AABB overlap ≤ 1e-5 | in range, overlap 0 |
| Outer AABB | (1.312, 1.312, 1.761) m ± 0.01 | (1.3120, 1.3120, 1.7606) |
| Grounded | bbox min Z within 1e-4 of 0 | 0.0000 / 0.0000 / 0.0000 |
| Named supports | all 12 bottom-course stones on the floor within 1e-4 | 12/12, worst 0.000000 |
| Hygiene | loose V/E, non-manifold, zero-area, doubles @1e-5, n-gons: all 0 | 0 / 0 / 0 on every axis |
| Z-fighting | coplanar cross-shell face pairs = 0 | 0 / 0 / 0 |
| Post tenon | each post seats 0.015–0.022 m into the measured coping top | 0.01800 / 0.01800 / 0.01800 |
| Post placement | each post within 0.02 rad, in plan, of a roof hip corner recomputed from the mesh | 0.00000 |
| Bucket clearance | hangs 0.085–0.115 m clear of the measured coping top | 0.10000 |
| Material-island gap | stone↔wood and metal↔wood min distance ≤ 0.008 m | 0.00000 / 0.00000 / 0.00000 |
| Collider tris | ≤ 380 | 258 |
| Export | written, size > 0, removed after measuring | 686472 / 686472 / 686468 bytes (4.5.11 / 5.1.2 / 5.2.1) |
DECIMATE COLLAPSE triangle counts are not guaranteed identical across series — the gate is a ratio band, not an exact count. This mesh happened to match on 4.5.11 / 5.1.2 / 5.2.1. Bake pixels are stochastic; the gate is has_data plus operator FINISHED, not byte-identity. Construction uses no RNG; the per-piece material tone is drawn from a seeded random.Random(TONE_SEED), the same every run. glTF byte size differs by a few hundred bytes across series; the gate is "written and non-empty", not a byte count, and the file is removed once measured.
Falsifiers#
Each flag breaks one stage so a named budget fails and the piece exits that code.
| Flag | Target budget | Exit |
|---|---|---|
--skip-decimate | LOD1 ratio band (ratio becomes 1.0) | 9 |
--lift-z | AABB grounded zmin (whole mesh up 0.05 m) | 16 |
--stand-posts | Coplanar cross-shell pairs — puts the posts back on the axis and stands them on the coping, which is the pair of choices the shipped piece made (0 → 4 pairs) | 15 |
--float-stone | Named supports — lifts one bottom-course stone 4 mm while the other eleven still ground the AABB | 16 |
--shallow-tenon | Post tenon band — seats the posts only 4 mm, too shallow to be a joint but not flush, so no faces share a plane | 18 |
--drop-bucket | Bucket clearance — lowers the bucket 0.26 m back down the shaft | 18 |
--turn-posts | Post placement — rotates the post ring one curb facet off the roof's hip corners | 19 |
Two of these had to be re-aimed, which is the point of declaring the target:
--stand-postsseats the posts flush and returns them to the axis. Flush alone, at the corrected 45°, leaves no coping top face withinCOPLANAR_CENTRE_MAXof a foot, so it fell through to the tenon band (18) and witnessed nothing about z-fighting.--turn-postsrotates by exactly one curb facet (30°). Any other angle sets the feet down on a different part of the 12-gon coping and the stone-wood gap gate (17) steals the failure; a full 45° also swings the crank grip past the eave and fails the AABB gate (8) — the same trapstone-archway's--flat-archfell into. One facet is the only rotation whose local seat geometry is identical by symmetry.
Run#
blender --background --python stone_well.py --
blender --background --python stone_well.py -- --skip-decimate
blender --background --python stone_well.py -- --lift-z
blender --background --python stone_well.py -- --stand-posts
blender --background --python stone_well.py -- --shallow-tenon
blender --background --python stone_well.py -- --turn-posts
blender --background --python stone_well.py -- --float-stone
blender --background --python stone_well.py -- --drop-bucket
blender --background --python stone_well.py -- --output well.pngSmoke passes none of the falsifier flags and no --output.
Exit codes#
File-local. 9 is a valid check code. 10 is reserved for gallery_framing.check_framing on the --output path.
| Code | Meaning |
|---|---|
| 0 | Success |
| 1 | Uncaught exception (FATAL wrapper) |
| 2 | argparse / usage |
| 3 | Mesh did not build / no UV layer |
| 4 | Base triangle count outside range |
| 5 | Material count ≠ 3 distinct slots, or a material face floor missed |
| 6 | UVs outside 0..1 |
| 7 | UV AABB overlap above tolerance |
| 8 | World AABB off declared outer size |
| 9 | LOD ratio band (--skip-decimate lands here) |
| 10 | Framing gate (render path only) |
| 11 | Collider triangle count above ceiling |
| 12 | Bake did not finish or image has no data |
| 13 | Export file missing or empty |
| 14 | --output produced no file |
| 15 | Hygiene: loose geometry, non-manifold, zero-area, doubles, n-gons, or coplanar cross-shell face pairs (--stand-posts lands here) |
| 16 | Bbox min Z not grounded (--lift-z), or a named support off the floor (--float-stone) |
| 17 | Material-island gap above tolerance (parts meant to touch) |
| 18 | Post tenon depth outside its band (--shallow-tenon), or bucket clearance outside its band (--drop-bucket) |
| 19 | A post not under a roof hip corner in plan (--turn-posts lands here) |
| 20 | Gallery asset-quality violation (render path; the floors' 11 is remapped here) |
