Lattice Deform

A runnable example that deforms a subdivided column with a 2×2×2 lattice set to 'KEY_LINEAR' interpolation on all three axes, then proves, vertex by vertex, that the Lattice modifier's output is exactly the trilinear interpolation of the eight deformed control points. The deformed mesh is read through the depsgraph lifetime contract from depsgraph-and-evaluated-data (evaluated_get → to_mesh → to_mesh_clear), and the lattice points are edited the way mesh-editing-and-bmesh recommends for data-level work: through bpy.data, never bpy.ops.

What it witnesses: LatticePoint.co is the read-only rest position and LatticePoint.co_deform is the one you move. With linear interpolation a vertex at normalized rest coordinates (u, v, w) inside the lattice lands on Σ wᵢ · co_deformᵢ with wᵢ = (u or 1−u)(v or 1−v)(w or 1−w), mapped through the lattice object's matrix. The check computes that closed form independently for all 602 vertices, through a lattice object that is translated and non-uniformly scaled (1.7 × 1.7 × 2.4), and requires agreement to 1e-5 in world space (measured: 5.6e-7). It also asserts the undeformed lattice is the identity and that the deformation is not trivially small (max displacement 0.53).

The trap it exposes: a new lattice defaults to 'KEY_BSPLINE'. B-spline weights smooth over the control points instead of interpolating them, so a script that moves a corner and expects the mesh to follow it linearly gets a softer, smaller pull. On a 2×2×2 lattice the rest state is still the identity, so nothing looks wrong until a point moves. --bspline keeps the default and fails check 4 with the measured error.

The still shows the rule as a before-and-after on a walnut plinth: on the left a render-only twin of the column, undeformed, inside its rest cage; on the right the checked column inside the deformed cage, with the two moved corners in selection orange and a short orange rod from each back to its rest position. The column carries a glazed two-tone checker in Generated (rest) coordinates, so the squares are square before the lattice acts, and their shear and taper in the still are the deformation. Lattices do not render, so both cages are drawn as thin steel rods built from the corner positions after the check has run.

Run#

# Cheap correctness check (no render) — the CI check:
blender --background --python lattice_deform.py --

# Falsifier: keep the default KEY_BSPLINE interpolation. Must exit 4.
blender --background --python lattice_deform.py -- --bspline

# Also render a still (EEVEE on a GPU host; use --engine cycles on GPU-less hosts):
blender --background --python lattice_deform.py -- --output lattice.png --engine cycles

Version notes#

The Lattice datablock API (points_u/v/w, interpolation_type_u/v/w, points[i].co / co_deform, point order u fastest, then v, then w) and the 'LATTICE' modifier are the same on 4.5 LTS, 5.1 and 5.2 LTS. Measured identically on 4.5.11, 5.1.2 and 5.2.1: 602 vertices, trilinear max error 5.6e-7, max displacement 0.5311; --bspline max error 0.2145.

Exit codes#

The blender-smoke workflow runs the check on Blender 5.2 LTS and 4.5 LTS (5.1 on the weekly cron, the needs-5.1 PR label, or manual dispatch). Smoke does not pass --output. Its catalog falsifier is --bspline (expects exit 4).
